IP250C & IP400C CRASH BUFFER TO UIC 573
Overall length 620mm buffer head 350 x 450
The buffers fully comply with UIC 573 annex F 250kJ and 400kJ requirements
The reversible element Oleo capsule type 40 fully complies with UIC 526 Cat.C requirements
The Cat.C reversible first stage of this crash buffer provides more capacity than any Cat.C insert and postpones accidental events.
Reversible
Gas-hydraulic capsule
Stroke: less than 105-5mm
Capacity: greater than 120kJ
Buffer force: IP250C is less than 1500kN
Buffer force: IP400C is less than 1800kN
Non Reversible
Stage:
Stroke: greater than 170mm
Capacity: greater than 120kJ
Average buffer force: IP250C – 1500kN
Average buffer force: IP400C – 1800kN
Total stroke: greater than 275mm
Total stroke: IP250C is greater than 250kJ
Total stroke: IP400C is greater than 450kJ
