Like the Type 9 the Type 50 can be used in applications such as overhead cranes in steel mills or on dockside cranes. The type 50 is rated to a lower max. force and, has a lower end force with strokes of 250mm, 300mm and 400mm. These are typically used on the main boom and main trolley on large STS cranes.
Metric | |
---|---|
Stroke | 400 mm |
Dynamic Capacity | 160 kJ |
Maximum End Force | 500 kN |
Static Start Force | 5 kN |
Static End Force | 60 kN |
